UPVC Door Flag Hinge Trojan Patriot Plus High Security 3D Adjustable PAS24

The Patriot Plus High Security Door Flag Hinge combines an aesthetically pleasing slim appearance, a great range of stylish colours with easy and accurate 3D adjustment, and offers no visible gap between flag and base (with height adjustment).

These hinges come pre-assembled and are ready to fit, making them very installer friendly! No visible fixings, improved clearance for plaster line and finishing, non-handed design, and additional location pins to reduce twist - all contribute to making these hinges a number one choice amongst fitters.

Features:

Pre-assembled ready to fit
Patented anti-lift feature
Non handed
Slim frame plate
No visible fixings
Additional location pins to reduce twist
Full 3D adjustment
Height: +8mm, Compression: +/- 1.5mm, Lateral: +/- 6mm
Vertical adjustment with no gap created between flag and base
Available in three heights: 16mm, 19mm and 22mm
Maximum Weight Carrying Capacity: 3 hinges carry 80KG
PAS 24 accredited as part of a door assembly
Corrosion tested to Grade 4
Conforms to EN1191 – tested to 100,000 cycles
Material: Zinc alloy, Stainless Steel - Grade 430, Plastic - GF Nylon, UV stabilised ABS and Acetal
Suitable for profile upstands from 16 to 22mm
